Sensor-1 PM2022 Population Planter/Drill Monitor 32 Row
Details
Product media
- The new Sensor-1 monitor is innovation at your fingertips designed to simplify and innovate your planting operation. It features the capability of seed monitoring 1-32 rows and is also capable of monitoring liquid application.
- 1-32 Row Monitoring System
- 10" Diagonal Monitor
- Works with existing Dickey-john or John Deere Harnesses
- NOTE: If ordering just the Monitor know your pin out to match your harness.
- Sensor-1 Monitor Pins out John Deere or Dickey-john
- John Deere - Power is in Pin 27, Ground is in Pin 28
- Dickey-john - (Under 12 Rows) Power is in pin 24, Ground is in Pin 28
- Dickey-john - (12 Rows and Over) Power is in Pins 24 & 25, Ground is in Pins 26 & 27
- Seed Population or Flow Sensors
- 4 Different types of Liquid Flow Sensors Capability
- Granular Fertilizer Flow
- Hopper, Shaft, (RPM), Air Pressure, Sensor Capability
- Display GPM, GPH, Seed Spacing, Acres/Hour, RPM, Field Acres
- Adjustable Alarm Volume
- On-the-fly Speed Adjustments
- English/Metric Measurements
- Can be used with seed flow sensors, high-rate population sensors or Accu sensors (singulation).
- 1-Year Warranty
